HCZ-6321

2MP 32x AHD Zoom Camera

Key Features
• Max. 2MP resolution
• Min. Illumination 0.2 Lux@F1.6 (Color), 0.01 Lux@F1.6 (B/W)
• 4.44 ~ 142.6mm (32x) optical zoom, 16x digital zoom
• Digital PTZ
• Day & Night (Auto ICR), WDR (120dB)
• Detection, Tracking, Fixed Moved, Tampering support
Contact Sales Datasheet

["camera","analog","analog-box"]

Product availability may vary by region.
Please contact your regional representative.

Hanwha Vision is formerly known as Hanwha Techwin.

Product Specification

Video
Imaging Device 1/2.8" CMOS
Resolution 1080p
Max. Framerate 30fps/25fps(60Hz/50Hz)
Min. Illumination Color: 0.2 Lux (1/30sec, F1.6)
B/W: 0.01 Lux (1/30sec, F1.6)
Video Out AHD: 1080p, BNC
CVBS: SD, DIP connector type
Video Transmission Distance 500m(5C2V Coaxial Cable)
Lens
Focal Length (Zoom Ratio) 4.44~142.6mm(32x) zoom
Max. Aperture Ratio F1.6(Wide)~F4.4(Tele)
Angular Field of View H: 62.8°(Wide)~2.23°(Tele) / V: 36.80°(Wide)~1.26°(Tele)
Min. Object Distance 1.5m(4.92ft)
Focus Control Auto, Manual, Oneshot AF
Lens type DC auto iris
Operational
Camera Title Displayed up to 15 characters
Day & Night Auto(ICR)
Backlight Compensation BLC, HLC, WDR, SSDR
Wide Dynamic Range 120dB
Digital Noise Reduction SSNRⅢ
Digital Image Stabilization Support
Defog Support
Motion Detection 4ea, rectangular zones
Privacy Masking 12ea, rectangular zones
Gain Control Low / Middle / High
White Balance ATW / AWC / Manual / Indoor / Outdoor
Electronic Shutter Speed Minimum / Maximum / Anti flicker (2 ~ 1/33,000sec)
Digital PTZ Support
Video Rotation H-REV/V-REV
Analytics Motion detection
Serial Interface RS-485: Samsung-T/E, Pelco-D/P, Panasonic, Bosch, AD, Vicon, Honeywell
Alarm I/O Output 1ea
Coaxial Protocol ACP(AHD Coax Protocol)
Environmental & Electrical
Operating Temperature / Humidity -10°C ~ +55°C (+14°F ~ +131°F) / Less than 90% RH
Storage Temperature / Humidity -10°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH
Input Voltage 12V DC
Power Consumption Max 6W
Mechanical
Color / Material Black / Metal
Product Dimensions / Weight 72(W)x63.9(H)x137.25(D)mm(2.83x2.52x5.40"), 451g(0.99 lb)
DORI
Detect (25PPM/ 8PPF) Wide: 62.9m(206.4ft) / Tele: 1973m(6473.05ft)
Observe (63PPM/ 19PPF) Wide: 25.2m(82.56ft) / Tele: 789.2m(2589.22ft)
Recognize (125PPM/ 38PPF) Wide: 12.6m(41.28ft) / Tele: 394.6m(1294.61ft)
Identify (250PPM/ 76PPF) Wide: 6.3m(20.64ft) / Tele: 197.3m(647.31ft)
