Analog Cameras
Discontinued
SCB-3000
High Resolution WDR Camera
Key Features
• Excellent high resolution 60OTV lines color images
• Low light sensitivity of min. 0.1Lux
• 2D/3D filtering noise reduction technology, SSNRIII
• 128x WDR (Wide Dynamic Range)
• ICR Day & Night function, 512x sens-up support
• PIP, coaxial control support
• Low light sensitivity of min. 0.1Lux
• 2D/3D filtering noise reduction technology, SSNRIII
• 128x WDR (Wide Dynamic Range)
• ICR Day & Night function, 512x sens-up support
• PIP, coaxial control support
Product availability may vary by region.
Please contact your regional representative.
Hanwha Vision is formerly known as Hanwha Techwin.
Product Specification
| Video | |
|---|---|
| Imaging Device | 1/3" Super HAD CCD II (Double scan) |
| NETD | 2 : 1 Interlace |
| Pixel Size | Color : 600TV lines, B/W : 700TV lines |
| Min. Illumination | 0.3Lux@F1.2 (50IRE), 0.0006Lux (Sens-up, 512x) |
| Video Out | CVBS : 1.0 Vp-p / 75Ω composite |
| Lens | |
| Lens type | Manual / Auto iris (Video / DC) |
| Mount Type | C / CS |
| Operational | |
| Motion Detection | Samsung-T/E, Pelco-D/P, Panasonic, Bosch, Honeywell, Vicon |
| Privacy Masking | Pelco-C (Coaxitron) |
| Gain Control | Fixed / Moved / Fence / Tracking / Detection / Counting |
| White Balance | Off / On |
| LDC | Off / On |
| Environmental & Electrical | |
| Operating Temperature / Humidity | -10°C ~ +55°C (+14°F ~ +131°F) |
| Storage Temperature / Humidity | Less than 90% RH |
| Input Voltage | Dual (24V AC & 12V DC ±10%) |
| Mechanical | |
| Color / Material | Black, Silver |
| RAL Code | Aluminum, Steel |
