| Video |
| Imaging Device |
1/2.8" CMOS |
| Resolution |
3840x2160, 3328x1872, 3072x1728, 2592x1944, 2688x1520, 1920x1080, 1600x1200, 1280x1024,1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240 |
| Max. Framerate |
H.265/H.264: Max. 30fps/25fps(60Hz/50Hz) (WDR on/off)
MJPEG: Max. 30fps(@8MP Max. 5fps) |
| Min. Illumination |
Color: 0.06Lux(F1.6, 1/30sec, 30IRE)
BW: 0.006Lux(F1.6, 1/30sec, 30IRE), 0Lux(IR LED on) |
| Video Out |
USB: Micro USB Type B, 1280x720 for installation |
| Lens |
| Focal Length (Zoom Ratio) |
3.2~10.2mm(3.2x) motorized varifocal |
| Optical Zoom |
3.2x |
| Max. Aperture Ratio |
F1.6(Wide)~F3.1(Tele) |
| Angular Field of View |
H: 104°(Wide)~31°(Tele)
V: 55°(Wide)~17°(Tele)
D: 124°(Wide)~35°(Tele) |
| Min. Object Distance |
1.2m (3.93ft) |
| Focus Control |
Simple focus |
| Lens Type |
DC auto iris(IR Corrected) |
| Pan / Tilt / Rotate |
| Pan / Tilt / Rotate Range |
0°~360° / 0°~100°/ 0°~360° |
| Operational |
| Camera Title |
Displayed up to 85 characters |
| Day & Night |
Auto(ICR) |
| Backlight Compensation |
BLC, WDR, SSDR |
| Wide Dynamic Range |
120dB |
| Digital Noise Reduction |
WiseNRⅡ(Based on AI engine)
SSNRⅤ |
| Motion Detection |
8ea, 8point polygonal zones |
| Privacy Masking |
32ea, 4point quadrangle zones
- Color: Gray/Green/Red/Blue/Black/White |
| Gain Control |
Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
| LDC |
Support |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (1/5~1/12,000sec) |
| Video Rotation |
Flip, Mirror, Hallway view(90°/270°) |
| Analytics |
Classified object type: Person/Vehicle(Type:car/bus/truck/motorcycle/bicycle)
Attributes: Person, Vehicle(Type:car/bus/truck/motorcycle/bicycle)
Support DetectionShot
Analytics events based on AI engine
- Motion detection*, Object detection, Virtual line*(Crossing/Direction), Virtual area*(Loitering/Intrusion/Enter/Exit)
Analytics events
- Defocus detection, Tampering, Virtual area(Appear/Disappear)
* Some of the video analytics only works with people and vehicle detection |
| Business Intelligence |
Based on AI engine: People counting, Vehicle counting, Queue management, Heatmap |
| Alarm I/O |
Input 1ea / Output 1ea |
| Alarm Triggers |
Analytics, Network disconnect, Alarm input, MQTT subscription |
| Alarm events |
When alarm trigger occurred
- File upload(image) : e-mail/FTP
- Notification : e-mail
- Recording : SD/SDHC/SDXC or NAS recording at event triggers
- Alarm output
- Handover(PTZ preset, Send message by HTTP/HTTPS/TCP)
- Audio clip playback
- MQTT: publication |
| Audio In |
Selectable(mic in/line in) |
| Audio Out |
Line out |
| IR Viewable Length |
30m(98.42ft) |
| IR Wavelength |
long-life 850 nm IR LED |
| Network |
| Ethernet |
RJ-45(10/100BASE-T) |
| Video Compression |
H.265/H.264: Main/High, MJPEG |
| Audio Compression |
G.711 u-law /G.726 Selectable
G.726(ADPCM) 8KHz, G.711 8KHz
G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps
AAC-LC: 48Kbps at 16KHz |
| Smart Codec |
Manual(5ea area), WiseStreamⅢ(Based on AI engine) |
| Bitrate Control |
H.264/H.265: CBR or VBR
MJPEG: VBR |
| Streaming |
Unicast(20 users) / Multicast
Multiple streaming(Up to 5 profiles) |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, CDP, SRTP(TCP, UDP Unicast), MQTT |
| Application Programming Interface |
ONVIF Profile S/G/T/M
SUNAPI(HTTP API)
Hanwha Vision Open Platform |
| Security |
| OS / Firmware Protect |
Encrypted firmware, Secure boot, Signed firmware |
| User authentication |
Digest Authentication, Prevent brute-force attack |
| Network authentication |
IEEE 802.1X(EAP-TLS, EAP-LEAP, EAP-PEAP, MSCHAPv2) |
| Secure Communication |
HTTPS, WSS(WebSocket Secure) |
| Access Control |
IP-based access control |
| Data Protect |
Encryption credentials, Encrypt compress for live recording file |
| Audit |
Access / System / Event Log management |
| Device ID |
Device certificate(Hanwha Vision Root CA) |
| Secure Storage |
SDcard partition encrypt |
| General |
| Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
| Edge Storage |
Micro SD/SDHC/SDXC 1slot 256GB |
| Memory |
2GB RAM, 1GB Flash |
| Environmental & Electrical |
| Operating Temperature / Humidity |
-30°C~+55°C(-22°F~+131°F) / 0~100% RH
* Start up should be done at above -30°C
Humidity control /w Air vent |
| Storage Temperature / Humidity |
-50°C~+60°C(-58°F~+140°F) / 0~95% RH |
| Certification |
IP66, IK10 |
| Input Voltage |
PoE(IEEE802.3af, Class3) |
| Power Consumption |
PoE: Max 12W, typical 5.3W |
| Mechanical |
| Color / Material |
White / Aluminum |
| RAL Code |
RAL9003 |
| Product Dimensions / Weight |
ø93.4x245.8mm(ø3.68x9.68"), 930g(2.05 Ib) |
| Compatible Conduit hole / Gangbox |
Conduit hole : None
Gangbox (SBO-090GP) : Single, Double, 4" Octagon (sold separately) |
| Certifications & Standards |
| EMC |
FCC 47 CFR 15 Subpart B Class A
ICES-3(A)/NMB-3(A)
CE/UKCA
- EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3
VCCI CISPR 32 Class A
RCM AS/NZS CISPR 32 Class A |
| Safety |
UL 62368-1, CAN/CSA C22.2 NO. 62368-1
IEC/EN 62471 |
| Environment |
IEC/EN 63000
IEC/EN 60529 IP66, IEC/EN 62262 IK10 |
| Compatible Models |
| Back Box |
SBO-140BW, SBO-140WW |
| Ceiling Mount (Single Unit) |
SBP-140CMT |
| Pole Mount |
SBD-140PMW |
| Corner Mount |
SBD-140KMB |
| Cabinet |
SBP-150NBW |
| Gang Plate |
SBO-090GP |
| DORI (EN62676-4 standard) |
| Detect (25PPM/ 8PPF) |
Wide: 60.0m(196.86ft) / Tele: 276.9m(908.57ft) |
| Observe (63PPM/ 19PPF) |
Wide: 24.2m(78.74ft) / Tele: 111.7m(363.43ft) |
| Recognize (125PPM/ 38PPF) |
Wide: 12.0m(39.37ft) / Tele: 55.4m(181.71ft) |
| Identify (250PPM/ 76PPF) |
Wide: 6.0m(19.69ft) / Tele: 27.7m(90.86ft) |
