Monitors
SMT-2740
27" UHD monitor
Key Features
• 27 inch UHD Monitor, support up to 3840×2160@60Hz
• Brightness 300 cd/m² (Typical), Contrast 900:1 (Minimum), 1200:1 (Typical)
• Viewing Angle (H/V) : 178°/178°, Response Time : 14ms (Typical)
• Video Input : HDMI, DP, two windows PIP/PBP
• Panel Life : 30,000 hours
• Designed and tested on 24/7 operation
• Brightness 300 cd/m² (Typical), Contrast 900:1 (Minimum), 1200:1 (Typical)
• Viewing Angle (H/V) : 178°/178°, Response Time : 14ms (Typical)
• Video Input : HDMI, DP, two windows PIP/PBP
• Panel Life : 30,000 hours
• Designed and tested on 24/7 operation
Product availability may vary by region.
Please contact your regional representative.
Hanwha Vision is formerly known as Hanwha Techwin.
Product Specification
| Display | ||
|---|---|---|
| Type | LED Monitor | |
| Screen Size | 27" | |
| Max. Resolution | 3840*2160 60Hz (UHD) | |
| Brightness | 300 cd/m²（Typ） | |
| Contrast Ratio | 900:1（Min）, 1200:1（Typ） | |
| Aspect Ratio | 16:9 | |
| Viewing Angle (H/V) | 178°/178° | |
| Display Color | 1.07B Colors(Typ) | |
| Response Time | 14ms(Typical) | |
| Panel Life | 30,000 hours | |
| Interface | ||
| Video | ||
| Connectors | HDMI 2.0(2), DP1.4(1), two windows PIP/PBP | |
| HDMI | ||
| Connector | HDMI | |
| Available Format | 640 x 480@60Hz, 800 x 600@56Hz/60Hz/72Hz/75Hz, 1024 x 768@60Hz/70Hz/75Hz, 1280 x 1024@60Hz/75Hz, 1440 x 900@60Hz, 1680 x 1050@60Hz, 1920 x 1080@50Hz/60Hz, 2560 ×1440@60Hz,'3840×2160@60Hz, 3840 x 2160P@30/50/60Hz, 720 x 480P60Hz, 1280 x 720P@50Hz, 720 x 576P@50Hz, 1920x1080P@50/60Hz, 1280 x 800@60Hz, 1280 x 960@60Hz, 1280 x 720@60Hz |
|
| DP | ||
| Connector | DP | |
| Available Format | 640 x 480@60Hz, 800 x 600@56Hz/60Hz/72Hz/75Hz, 1024 x 768@60Hz/70Hz/75Hz, 1280 x 1024@60Hz/75Hz, 1440 x 900@60Hz, 1680 x 1050@60Hz, 1920 x 1080@50Hz/60Hz, 2560 ×1440@60Hz,'3840×2160@60Hz, 3840 x 2160P@30/50/60Hz, 720 x 480P60Hz, 1280 x 720P@50Hz, 720 x 576P@50Hz, 1920x1080P@50/60Hz, 1280 x 800@60Hz, 1280 x 960@60Hz, 1280 x 720@60Hz |
|
| Audio | ||
| Connector | Audio Out | |
| Output Signal | Loop-through line level(PC only), Speakers : 4Ω 2.5Wx 2 | |
| On Screen Display | ||
| Functions | VESA™ DPM Compatible | |
| Language | Korean, English, Pусский, Deutsch, Français, Españo, Italiano, Português, Chinese (Simplified), Chinese (Traditional), Japanese, Arabic | |
| General | ||
| Electrical | ||
| Input Voltage | AC 100 ~ 240V(50/60Hz) | |
| Power Consumption | <45W | |
| Environmental | ||
| Operating Temperature | 0 ~ +40°C (+32°F ~ +104°F) | |
| Operating Humidity | 10% ~ 80% (non-condensing) | |
| Mechanical | ||
| Dimensions with Stand (WxHxD) | 614.7*452.5*224.1mm | |
| Dimensions without Stand (WxHxD) | 614.7*336.4*50.8mm | |
| Weight | 5.04Kg(with stand), 4.63Kg(without stand) | |
| Cabinet Color | Black | |
| VESA Mounts Interface | 100*100mm | |
