SCD-6025R
2MP Analog IR Dome Camera
• 0.17Lux@F1.6 (Color), 0Lux (B/W : IR LED on)
• Built-in 4mm fixed lens
• Day & Night (ICR)
• SSNRⅣ, Motion detection
• IR viewable length 20m (65.62ft)
• Transmission distance max.500m
Product availability may vary by region.
Please contact your regional representative.
Hanwha Vision is formerly known as Hanwha Techwin.
Product Specification
| Video | ||
|---|---|---|
| Imaging Device | 1/2.8" CMOS | |
| Resolution | 1920x1080 | |
| Max. Framerate | 30fps/25fps(60Hz/50Hz) | |
| Min. Illumination | Color: 0.17Lux (F1.6, 1/30sec) \nBW: 0Lux(IR LED on) | |
| Video Out | BNC(AHD 2MP,CVBS) | |
| Video Transmission Distance | 500m(5C2V Coaxial Cable) | |
| Lens | ||
| Focal Length (Zoom Ratio) | 4mm fixed | |
| Max. Aperture Ratio | F1.6 | |
| Angular Field of View | H : 87.6°, V : 46.4°, D : 104.5° | |
| Min. Object Distance | 0.5m(1.64ft) | |
| Lens Type | DC auto iris | |
| Pan / Tilt / Rotate | ||
| Pan / Tilt / Rotate Range | 0° ~ 350° / 0° ~ 67° / 0° ~ 355° | |
| Operational | ||
| Camera Title | Displayed up to 15 characters | |
| Day & Night | Auto(ICR) | |
| Backlight Compensation | BLC, HLC, DWDR | |
| Digital Noise Reduction | SSNRⅣ | |
| Defog | Support | |
| Motion Detection | 4ea | |
| Privacy Masking | 8ea, rectangular zones | |
| Gain Control | Low / Middle / High / Very High | |
| White Balance | ATW / AWC / Manual / Indoor / Outdoor | |
| Electronic Shutter Speed | 1 ~ 1/12,000sec | |
| Video Rotation | H-REV / V-REV / HV-REV | |
| Analytics | Motion detection | |
| Alarm I/O | Output 1ea | |
| Alarm Triggers | Analytics | |
| Alarm Events | Alarm output | |
| IR Viewable Length | 20m (65.62ft) | |
| Coaxial Protocol | ACP(AHD Coax Protocol)\nCVBS: Pelco-C(Coaxitron) | |
| Environmental & Electrical | ||
| Operating Temperature / Humidity | -10°C ~ +55°C (+14°F ~ +131°F) / \nLess than 90% RH | |
| Input Voltage | DC 12V | |
| Power Consumption | DC 12V/0.45A (Max 5.4W) | |
| Mechanical | ||
| Color / Material | Ivory / Plastic | |
| Product Dimensions / Weight | Ø110 x 86mm(4.33 x 3.39"), 227g(0.50 lb) | |
| Hanging Mount (Dome) | SBP-300HM7 | |
| DORI (EN62676-4 standard) | ||
| Detect (25PPM/ 8PPF) | 40m(131.38ft) | |
| Observe (63PPM/ 19PPF) | 16m(52.55ft) | |
| Recognize (125PPM/ 38PPF) | 8.0m(26.28ft) | |
| Identify (250PPM/ 76PPF) | 4.0m(13.14ft) | |
