Network Cameras

XNP-8300RW

6MP 30x IR PTZ with built-in wiper

Key Features
• Max. 6MP resolution
• 5~150mm(30x) optical zoom (digital 32x, total 960x zoom)
• Max. IR viewable length 200m
• Day & Night(ICR), extreme WDR, DIS(Built-in gyro sensor)
• Intelligenct Analytics, Object auto tracking(Person/Vehicle), Target lock tracking
• H.264, H.265, MJPEG codec, WiseStreamII
• IP66, IK10, NEMA4X, NEMA-TS 2(2.2.8, 2.2.9)
• PTZ PLUS Design applied(Compact, Lighter, Simple cabling)
• SFP-supported by injector
Contact Sales Datasheet

["camera","network","ptz"]

Product availability may vary by region.
Please contact your regional representative.

Hanwha Vision is formerly known as Hanwha Techwin.

Overview

6MP resolution and 30x zoom, powerful PTZ performance
PTZ PLUS supports remarkable performance with new in-house developed 6MP 30x zoom lens. Experience powerful new PTZ’s performance.
AI based object auto tracking
PTZ PLUS supports object (person or vehicle) auto tracking based on AI deep-learning algorithm.



And by simply right-clicking an object on a screen, it locks the object and tracks the targeted object. (target-lock tracking)
Wise IR, offering optimized IR at every zoom ratio
PTZ PLUS allows for monitoring in complete darkness up to 200meters with Wise IR. It optimizes amount of IR at every zoom ratio.



Product Specification

Video
Imaging Device 1/2.8" CMOS
Resolution 3328x1872, 3072x1728, 2592x1944, 2688x1520, 1920x1080, 1600x1200, 1280x1024, 1280x960, 1280x720,
1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240
Max. Framerate H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
MJPEG: Max. 30fps/25fps(60Hz/50Hz) (@6MP Max. 5fps)
Min. Illumination Color: 0.1Lux(F1.6, 1/30sec)
BW: 0Lux(IR LED On)
Lens
Focal Length (Zoom Ratio) 5~150mm(30x) zoom (digital 32x, total 960x zoom)
Optical Zoom 30x
Max. Aperture Ratio F1.6(Wide) - F4.56(Tele)
Angular Field of View H: 57.42°(Wide)~2.19°(Tele) / V: 33.54°(Wide)~1.25°(Tele)
Min. Object Distance 3m(9.84ft)
Focus Control Oneshot AF, Focus save
Lens Type DC auto iris
Pan / Tilt / Rotate
Pan Range 360° Endless
Pan Speed Max. 500°/sec, Manual: 0.024°/sec~250°/sec
Tilt Range 110°(90°~-20°)
Tilt Speed Max. 350°/sec, Manual: 0.024°/sec~250°/sec
Sequence Preset(300ea), Swing, Group(6ea), Trace, Tour, Auto Run, Schedule
Preset Accuracy ±0.1°, Pan/Tilt correction
Operational
Camera Title Displayed up to 85 characters
Direction Indicator Support
Day & Night Auto(ICR)
Backlight Compensation BLC, HLC, WDR, SSDR
Wide Dynamic Range Extreme WDR(120dB)
Digital Noise Reduction SSNRⅤ
Digital Image Stabilization Support(built-in gyro sensor)
Defog Support
Motion Detection 8ea, 8point polygonal zones
Privacy Masking 32ea, 4point Quadrangle zones
- Color: Gray/Green/Red/Blue/Black/White
- Mosaic
Gain Control Manual / Max
White Balance ATW /Narrow ATW /AWC /Manual /Indoor /Outdoor /Mercury /Sodium
Electronic Shutter Speed Minimum / Maximum / Anti flicker (2~1/12,000sec)
Video Rotation Flip&Mirror
Analytics Directional detection, Fog detection, Face detection, Motion detection, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line, Shock detection
* Audio detection, Sound classification(with NW I/O Box)
Alarm Triggers Analytics, Network disconnect
* Alarm input(with NW I/O Box)
Alarm Events When alarm trigger occurred
- File upload(image) : e-mail/FTP/SFTP
- FIle upload(video clip): FTP/SFTP
- Notification : e-mail
- Recording : SD/SDHC/SDXC or NAS recording at event triggers
- Handover: PTZ preset, send message by HTTP/HTTPS/TCP
- Audio clip playback
- MQTT: publication
* Alarm output (Via optional I/O box SPM-4210)
Light Type IR LED(850nm)
IR Viewable Length 200m(656.17ft), Wise IR
Water Removal Support(with Wiper, Lens heater)
Auto Tracking Support
Object auto tracking(Person/Vehicle)
Target lock tracking
Network
Ethernet Metal shielded RJ-45(10/100BASE-T)
Video Compression H.265/H.264: Main/Baseline/High, MJPEG
Smart Codec Manual(5ea area), WiseStreamⅡ
Bitrate Control H.264/H.265: CBR or VBR
MJPEG: VBR
Streaming Unicast(20 users) / Multicast (128 user)
Multiple streaming(Up to 10 profiles)
Protocol IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP/SFTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, CDP, SRTP(TCP, UDP Unicast), NTCIP1205, MQTT
Application Programming Interface ONVIF Profile S/G/T
SUNAPI(HTTP API)
Hanwha Vision Open Platform
Security
OS / Firmware Protect Encrypted Firmware, Secure boot, Signed Firmware
User authentication Digest Authentication, Prevent brute-force attacks
Network authentication IEEE 802.1X(EAP-TLS, EAP-LEAP, EAP-PEAP, MSCHAPv2)
Secure Communication HTTPS, WSS(WebSocket Secure), SRTP
Access Control IP-based access control
Data Protect Encryption Credentials, Encrypt compress for live recording file export
Audit Access / System / Event Log management
Device ID Device certificate(Hanwha Vision Root CA)
Secure Storage HTPM(Hanwha trusted platform module), SDcard partition encrypt
Security Certificate CyberSecurity assuarance program UL CAP(UL 2900-2-3 L2)
General
Webpage Language English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish,
Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek
Edge Storage Micro SD/SDHC/SDXC 2slot 1TB
Memory 4GB RAM, 512MB Flash
Environmental & Electrical
Operating Temperature / Humidity -40°C~+55°C(-40°F ~ +131°F) /
+74°C(+165°F) (MAX) based on NEMA-TS 2(2.2.7)
* Start up should be done at above -30°C
0~100%RH(Condensing) Humidity control with AIR vent
Storage Temperature / Humidity -50°C ~ +60°C (-58°F ~ +140°F) / Less than 90% RH
Certification IP66, IK10, NEMA4X, NEMA-TS 2(2.2.8, 2.2.9)
Input Voltage PoE++(IEEE802.3bt, Class6, Type3, Injector included)
Power Consumption Typical 20W, Max 42W
Mechanical
Color / Material White, Black / Aluminum+Polycarbontate
RAL Code White: RAL9003 / Black: RAL9005
Product Dimensions / Weight ø184.9x318.8mm(7.28x12.55") / 5400g(11.90lb)
Hanging Mount (Dome) SBP-156HMW
Ceiling Mount (Assy) SBP-156CMW, SBP-300CMTS, SBP-300CMW1/900CMW, SBP-150CMI/300CMI
Wall Mount SBP-156WMW, SBP-390WMW2
Pole Mount SBP-300PMW2
Parapet Mount SBP-156LMW, SBP-156LMW1, SBP-300LMW
Corner Mount SBP-156KMW, SBP-300KMW1
Cabinet SBP-300NBW
DORI (EN62676-4 standard)
Detect (25PPM/ 8PPF) Wide: 121.5m(398.7ft) / Tele: 3482.3m(11424.9ft)
Observe (63PPM/ 19PPF) Wide: 48.6m(159.5ft)/ Tele: 1392.9m(4570.0ft)
Recognize (125PPM/ 38PPF) Wide: 24.3m(79.7ft)/ Tele: 696.5m(2285.0ft)
Identify (250PPM/ 76PPF) Wide: 12.2m(39.9ft) / Tele: 348.2m(1142.5ft)
