ネットワークカメラ

QNV-6012R

2M H.265 ネットワーク IR付 耐衝撃ドームカメラ

Key Features
• 最大2MP(1920 x 1080)の解像度
• 0.03Lux(カラー)、0Lux(白黒、IR LEDオン)
• 2.8mm固定レンズ
• すべての解像度で最大30fps@2M(H.265/H.264)
• H.265、H.264、MJPEG対応
• モーション検知、いたずら検知、焦点ぼけ検知
• 縦表示モード(ホールウェイビュー)(90°/270°)、LDCサポート
• microSD/SDHC/SDXCメモリースロット(最大128GB)
• IR照射距離20m
• IP66、IK10、PoE、12VDC

["camera","network","dome"]

Product availability may vary by region.
Please contact your regional representative.

Hanwha Vision is formerly known as Hanwha Techwin.

Overview

High quality cameras offering cost effective solutions
The Q series cameras are affordable products that offer essential features in creating a safe and secure environment.
High quality cameras offering cost effective solutionsHigh quality cameras offering cost effective solutions
5MP and 2MP resolutions
The Q series offers two resolutions options to give you the freedom to choose the camera that best fits your security needs. The 5MP cameras can support up to 30fps, providing real-time video with 2592 x 1944 resolution and up to 15fps of WDR performance, providing crisp and vivid monitoring.
5MP and 2MP resolutions5MP and 2MP resolutions
Enhanced video analytics
The Q series cameras are equipped with a wide range of Intelligent Video Analytics features, helping users detect different types of incidents and have full situational awareness of their facility.
Enhanced video analyticsEnhanced video analytics
Hallway view for monitoring vertical shaped areas
In a vertical shaped environment, such as a store aisle, traditional horizontal shaped cameras waste bandwidth and storage on unnecessary edges. The Hallway view creates 3 : 4 and 9 : 16 ratio video which is vertically oriented and maximizes image quality in a narrow environment.
Hallway view for monitoring vertical shaped areasHallway view for monitoring vertical shaped areas

製品の仕様

映像
映像素子 1/2.8" CMOS
解像度 1920x1080, 1280x960, 1280x720, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360
最大フレームレート H.265/H.264: Max. 30fps/25fps(60Hz/50Hz)
MJPEG: Max. 15fps (@2MP Max. 4fps)
最低照度 Color: 0.03Lux(F2.0, 1/30sec)
BW: 0Lux(IR LED on)
映像出力 CVBS: 1.0 Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation
レンズ
焦点距離 2.8mm fixed focal
最大口径比 F2.0
画角 H: 114° / V: 62° / D: 135°
最低被写体距離 0.5m (1.64ft)
フォーカス制御 Fixed
パンニング/チルト/回転
パンニング/チルト/回転範囲 0˚~350˚ / 0˚~67˚ / 0˚~355˚
カメラ機能
カメラタイトル Displayed up to 85 characters
デイナイト Auto(ICR)
逆光補正 BLC, WDR, SSDR
Wide Dynamic Range 120dB
ノイズ軽減 SSNR
モーション検知 4ea, polygonal zones
プライバシーマスク 6ea, rectangular zones
ゲイン制御 Low / Middle / High
ホワイトバランス ATW / AWC / Manual / Indoor / Outdoor
LDC(レンズ歪曲補正) Support
電子シャッター Minimum / Maximum / Anti flicker (1/5~1/12,000sec)
映像回転 Flip, Mirror, Hallway view(90˚/270˚)
インテリジェントビデオ Motion detection, Tampering, Defocus detection , Virtual area(Intrusion/Enter/Exit), Virtual line(Crossing/Direction)
アラーム入出力 Input 1ea / Output 1ea
アラームトリガー Analytics, Network disconnect, Alarm input
アラームイベント File upload via FTP and e-mail
Notification via e-mail
SD/SDHC/SDXC or NAS recording at event triggers
Alarm output
Handover(PTZ preset)
音声入力 Selectable(mic in/line in)
Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm
Light Type IR LED (850nm)
Light Viewable Length 20m(65.62ft)
ネットワーク
イーサネット RJ-45(10/100BASE-T)
映像圧縮 H.265/H.264: Main/High, MJPEG
音声圧縮 G.711 u-law /G.726 Selectable
G.726(ADPCM) 8KHz, G.711 8KHz
G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps
スマートコーデック WiseStreamⅡ
ビットレート制御 H.264/H.265: CBR or VBR
MJPEG: VBR
ストリーミング性能 Unicast(6 users) / Multicast
Multiple streaming(Up to 3 profiles)
プロトコル IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP
応用インターフェイス ONVIF Profile S/G/T
SUNAPI(HTTP API)
Wisenet open platform
Security
OS / Firmware Protect Firmware encryption
User authentication Digest Authentication, Prevent brute-force attack
Network authentication 802.1X Authentication(EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2)
Secure Communication HTTPS, SRTP, WSS(Websocket secure)
Access Control Access control based on IP address
Data Protect Authentication information encryption, ZIP compression encryption
Audit User Access/System/Event log management
Device ID Device Certificate(Hanwha Private Root CA)
Secure Storage SDcard partition encrypt
一般
ウェブビューワー言語 English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish, Portuguese, Czech, Polish, Turkish, Dutch
SDカード Micro SD/SDHC/SDXC 1slot 128GB
メモリー 512MB RAM, 256MB Flash
動作環境/電源
動作温度/湿度 -30°C~+55°C(-22°F ~ +131°F) / 0~90% RH
* Start up should be done at above -20°C
保管温度/湿度 -30°C~+60°C(-22°F ~ +140°F) / 0~90% RH
規格認証 IP66, IK10
電源 PoE(IEEE802.3af, Class3), 12VDC
消費電力 PoE: Max 7.40W, typical 6.00W
12VDC: Max 6.40W, typical 5.10W
物理的仕様
カラー/材質 White / Aluminum
RAL コード RAL9003
寸法/重量 ø120.3x91.7mm(ø4.74x3.61"), 510g(1.12 Ib)
互換 Conduit hole / Gangbox - SBO-120GP : Single, Double, 4" Octagon
耐衝撃ドーム SBP-122HMW
バックボックス SBV-120GW
DORI (EN62676-4 standard)
Detect (25PPM/ 8PPF) 25.1m(82.21ft)
Observe (63PPM/ 19PPF) 10.0m(32.89ft)
Recognize (125PPM/ 38PPF) 5.0m(16.44ft)
Identify (250PPM/ 76PPF) 2.5m(8.22ft)
