Network Cameras

TID-600R

2MP Intercom

Key Features
• 1/2.8” 2MP sensor
• 1.6mm fixed lens : HFoV 180°, VFoV 114°
• IR viewable length 5m
• Built-in mic and speaker : 85dB speaker out at 0.5m
• Echo cancellation and noise reduction
• Touchless call, Built-in tamper switch
• SIP 2.0 support
• MicroSD 1slot, PoE/12VDC
Max. 550mA relay out with 2A 12VDC adapter
• IP65, IK08, NEMA4X
Contact Sales Datasheet

["camera","network","intercom"]

Product availability may vary by region.
Please contact your regional representative.

Hanwha Vision is formerly known as Hanwha Techwin.

Tổng quan


Wide Field of View for a wide range of applications
TID-600R has a wide field of view, 180 ̊ horizontal and 114 ̊ vertical. Making it suitable for various applications as TID-600R can capture from 14.2 inches (36cm) to 100.4 inches (255cm) tall objects (When an object is 29.5 inches away from the station)
*Various applications including Kindergarten, Nurshing home, Residence, Commercial building, Warehouse, and more

Various mounting options for a greater versatility
TID-600R is designed to be used at various business areas. Its small and slim from factor and contemporary product design offer both style and functionality. With multiple mounting options, covers and skin, it fits perfectly with its surroundings.



Touchless call as an essential post COVID-19 safety protocol
The ToF sensor of TID-600R allows touchless call, where users simply present their palm within 6 inches of the station to initiate a call. Touchless system is getting more and more important especially when there’s a highly contagious diseases and outbreaks.
*It also offers a push-button call

Thông số sản phẩm

Video
Imaging Device 1/2.8" CMOS
Resolution 1920x1080, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240
Max. Framerate H.265/H.264: Max. 60fps/50fps(60Hz/50Hz)
MJPEG: Max. 30fps
Min. Illumination Color: 0.018Lux(F1.6, 1/30sec)
BW: 0Lux(IR LED on)
Video Out CVBS: 1.0Vp-p / 75Ω composite, 720x480(N), 720x576(P) for installation
Lens
Focal Length (Zoom Ratio) 1.6mm fixed focal
Max. Aperture Ratio F1.6
Angular Field of View H: 180° / V: 114° / D: 180°
Min. Object Distance 0.3m (0.98ft)
Focus Control Fixed
Operational
Camera Title Displayed up to 85 characters
Day & Night Auto(ICR)
Backlight Compensation BLC, HLC, WDR, SSDR
Wide Dynamic Range 150dB
Digital Noise Reduction SSNRⅤ
Digital Image Stabilization Support
Defog Support
Motion Detection 8ea, 8point Polygonal zones
Privacy Masking 32ea, polygonal zones
- Color: Grey/Green/Red/Blue/Black/White
- Mosaic
Gain Control Low / Middle / High
White Balance ATW / AWC / Manual / Indoor / Outdoor
Electronic Shutter Speed Minimum / Maximum / Anti flicker (2~1/12,000sec)
Analytics Directional detection, Motion detection, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line, Audio detection, Shock detection, Sound classification
Alarm I/O Input 2ea / Output 1ea, Relay out 1ea (12VDC Max. 550mA with 2A adapter)
Tampering switch, Touchless call
Alarm Triggers Analytics, Network disconnect, Alarm input
Alarm Events File upload via FTP and e-mail
Notification via e-mail
SD/SDHC/SDXC or NAS recording at event triggers
Alarm output
Handover
Audio playback
Audio Streaming Two-way/one-way selectable, Full duplex, Echo cancellation and noise reduction
Audio In Built-in mic
Audio Out Built-in speaker: 85dB at 0.5m(1.64ft)
Light Type IR LED (850nm)
Light Viewable Length 5m
Network
Ethernet Metal shielded RJ-45(10/100BASE-T)
Video Compression H.265/H.264: Main/Baseline/High, MJPEG
Audio Compression G.711 u-law /G.726 Selectable
G.726(ADPCM) 8KHz, G.711 8KHz
G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps
AAC-LC: 48Kbps at 16KHz
Opus 8/16KHz
Smart Codec Manual(5ea area), WiseStreamⅡ
Bitrate Control H.264/H.265: CBR or VBR
MJPEG: VBR
Streaming Unicast(20 users) / Multicast
Multiple streaming(Up to 10 profiles)
Protocol IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, SRTP, SIP 2.0(RFC 3261 and companion RFCs)
SIP support (VoIP, Peer-to-peer, SIP/PBX integration) Tested with Cisco, Grandstream, Yealink VoIP phones and Asterisk PBX software
Security HTTPS(SSL) login authentication, Digest login authentication, IP address filtering, User access log, 802.1X authentication(EAP-TLS, EAP-LEAP),
Device certificate(Hanwha Techwin Root CA)
Application Programming Interface ONVIF Profile S
SUNAPI(HTTP API)
Wisenet open platform
General
Webpage Language English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek
Edge Storage Micro SD/SDHC/SDXC 1slot 256GB
Memory 2GB RAM
Environmental & Electrical
Operating Temperature / Humidity -30°C~+55°C(-22°F~+131°F) / 0~95% RH
Storage Temperature / Humidity -50°C~+55°C(-58°F~+131°F) / Less than 95% RH
Certification IP65, IK08, NEMA4X, Safety(UL), EMC(FCC, CE)
Input Voltage PoE(IEEE802.3af, Class3), 12VDC
Power Consumption PoE: Max 12.95W, typical 9.1W
12VDC: Max 17.6W, typical 7W
* 12VDC power consumption includes 12VDC/550mA relay out.
Mechanical
Color / Material Dark gray / Aluminum
RAL Code RAL7022
Product Dimensions / Weight 49(W)x165(H)x48(D)mm(1.93x6.50x1.89") / 490g(1.08lb)
Compatible Models
In-ceiling Mount SHS-165F
Tilt Mount SBS-165TM
Skin Cover SBC-165W
DORI (EN62676-4 standard)
Detect (25PPM/ 8PPF) 20.72m(67.98ft)
Observe (63PPM/ 19PPF) 8.29m(27.20ft)
Recognize (125PPM/ 38PPF) 4.14m(13.58ft)
Identify (250PPM/ 76PPF) 2.07m(6.79ft)
